System BIOS
Setup Item Options
Detected USB
Devices
USB Controller
Enabled
Disabled
Legacy USB
Enabled
Support
Disabled
Auto
Device Reset 10 sec
timeout
20 sec
30 sec
40 sec
Storage Emulation
One line for each
Auto
mass storage
Floppy
device in system
Forced FDD
Hard Disk
CD-ROM
USB 2.0
Enabled
controller
Disabled
4.3.2.2.6 PCI Screen
The PCI Screen provides fields to configure PCI add-in cards, the onboard NIC controllers, and
video options.
To access this screen from the Main screen, select Advanced | PCI.
Revision 1.8
Table 26. Setup Utility — USB Controller Configuration Screen Fields
[Enabled] - All onboard USB controllers will be turned on
and accessible by the OS.
[Disabled] - All onboard USB controllers will be turned off
and inaccessible by the OS.
PS/2 emulation for USB keyboard and USB mouse
devices.
[Auto] - Legacy USB support will be enabled if a USB
device is attached.
USB Mass storage device Start Unit command timeout.
[Auto] - USB devices less than 530MB will be emulated as
floppy.
[Forced FDD] - HDD formatted drive will be emulated as
FDD (e.g., ZIP drive).
Onboard USB ports will be enabled to support USB 2.0
mode.
Contact your OS vendor regarding OS support of this
feature.
Intel Order Number: E14960-009
Intel® Server Boards S3200SH/S3210SH TPS
Help Text Comments
Information only: Shows number of
connected USB devices
Header for next line.
This setup screen can show a
maximum of eight devices on this
screen. If more than eight devices
are installed in the system, the "USB
Devices Enabled" displays the
correct count, but only the first eight
devices can display here.
