3.4.2.2 APIC Interrupt Routing
For APIC mode, the server board interrupt architecture incorporates three Intel
devices to manage and broadcast interrupts to local APICs in each processor. The Intel
APICs monitor each interrupt on each PCI device including PCI slots in addition to the ISA
compatibility interrupts IRQ (0-15).
When an interrupt occurs, a message corresponding to the interrupt is sent across a three-wire
serial interface to the local APICs. The APIC bus minimizes interrupt latency time for
compatibility interrupt sources. The I/O APICs can also supply greater than 16 interrupt levels to
the processor(s). This APIC bus consists of an APIC clock and two bi-directional data lines.
3.4.2.3 Legacy Interrupt Sources
Table 16 recommends the logical interrupt mapping of interrupt sources on the board. The
actual interrupt map is defined using configuration registers in the Intel
ISA Interrupt
INTR Processor interrupt.
NMI NMI to processor.
IRQ0 System timer
IRQ1 Keyboard interrupt.
IRQ2 Slave PIC
IRQ3 Serial port 1 interrupt from Super I/O* device, user-configurable.
IRQ4 Serial port 1 interrupt from Super I/O* device, user-configurable.
IRQ5
IRQ6 Floppy disk.
IRQ7 Generic
IRQ8_L Active low RTC interrupt.
IRQ9 SCI*
IRQ10 Generic
IRQ11 Generic
IRQ12 Mouse interrupt.
IRQ13 Floaty processor.
IRQ14 Compatibility IDE interrupt from primary channel IDE devices 0 and 1
IRQ15 Secondary IDE Cable
SMI* System Management Interrupt: General purpose indicator sourced by the Intel
processor
3.4.2.4 Serialized IRQ Support
The server board supports a serialized interrupt delivery mechanism. Serialized Interrupt
Requests (SERIRQ) consist of a start frame, a minimum of 17 IRQ / data channels, and a stop
frame. Any slave device in the quiet mode may initiate the start frame. While in the continuous
mode, the start frame is initiated by the host controller.
Revision 1.8

Table 16. Interrupt Definitions

Description
Intel Order Number: E14960-009
Functional Architecture
®
I/O APIC
®
I/O
®
ICH9R.
®
ICH9R to the
31
