Figure 3. Intel - Intel S3200SHV - Entry Server Board Motherboard Specification

Intel® Server Boards S3200SH/S3210SH TPS
The following figure shows the board layout of the Intel
A letter identifies each connector and major component (shown in Table 3).
KK
JJ
II
HH
GG
FF
EE
DD
CC
BB
AA
Z
Y
X

Figure 3. Intel

®
Table3. Intel Server Boards S3200SH-L/S3200SH-V Component Layout Reference
Ref Description
A PCI (32-bit/33 MHz) Slot 1
B PCI (32-bit/33 MHz) Slot 2
C PCI Express* x8 (x4 lane)
D PCI Express* x16 (x8 lane)
E System Fan 1 Connector
F Back Panel Connectors
G Diagnostic LEDs
H Processor Fan 1 Connector
I 2X4 Aux Power Connector
J Processor Socket
K Channel 2 DIMM Sockets
L Channel 1 DIMM Sockets
Revision 1.8
A B C D E
W V U T S R Q P O
®
Server Board S3200SH-L/S3200SH-V SKU Diagram
Ref
M System Fan4 Connector
N System Fan3 Connector
O Battery
P Main Power Connector
Q System Fan2
R Floppy Connector
S SGPIO
T SATA 0
U HSBP
V SATA1
W SATA2
X IPMB
Intel Order Number: E14960-009
® Server Boards S3200SHL/S3200SHV.
F G
N M L K
Description Ref
Y
Z
AA
BB
CC
DD
EE
FF
GG
HH
II
JJ
KK
Server Board Overview
H
I
J
AF002310
Description
Front Panel Header
SATA 4
SATA 5
SATA 3
Internal USB
External USB
CMOS Clear Jumper
Password Clear Jumper
Recovery Mode Jumper
Serial Port
BMC Boot Block WP Jumper
Chassis Intrusion
BMC Force Update Jumper
