Intel® Server Boards S3200SH/S3210SH TPS
1.

Introduction

This Technical Product Specification (TPS) provides a high-level technical description for the
Intel ® Server Boards S3200SH/S3210SH. It details the architecture and feature set for all
functional sub-systems that make up the server boards.
Note: The document uses the term "server board" throughout and it applies to all four board
SKUs. When exceptions occur, the document calls out the specific board by name.
1.1

Chapter Outline

This document contains the following chapters:
Chapter 1 – Introduction
Chapter 2 – Server Board Overview
Chapter 3 – Functional Architecture
Chapter 4 – System BIOS
Chapter 5 – Error Reporting and Handling
Chapter 6 – Connectors and Jumper Blocks
Chapter 7 – Absolute Maximum Ratings
Chapter 8 – Design and Environmental Specifications
Chapter 9 – Hardware Monitoring
Glossary
Reference Documents
1.2

Server Board Use Disclaimer

Intel Corporation server boards support add-in peripherals and contain a number of high-density
VLSI and power delivery components that need adequate airflow to cool. Intel ensures through
its own chassis development and testing that when Intel server building blocks are used
together, the fully integrated system will meet the intended thermal requirements of these
components. It is the responsibility of the system integrator who chooses not to use Intel
developed server building blocks to consult vendor datasheets and operating parameters to
determine the amount of airflow required for their specific application and environmental
conditions. Intel Corporation cannot be held responsible if components fail or the server board
does not operate correctly when used outside any of the published operating or non-operating
limits.
Revision 1.8
Intel Order Number: E14960-009
Introduction
1
