Functional Architecture
3.5

BMC Controller

The Integrated Baseboard Management Controller (Integrated BMC) is a highly integrated
single-chip solution, integrating several devices typically found on servers. The Integrated BMC
is mainly targeted at next generation servers and provides a highly-integrated server class
product.
The Integrated BMC contains the following integrated subsystems and features.
Server Class Super I/O* functionality includes
Keyboard style/BT interface for BMC support
Two Fully Functional Serial Ports, compatible with the 16C550
Serial IRQ Support
SMI/SCI/PME Support
ACPI Compliant
Up to 16 Shared GPIO ports
Programmable Wake-up Event Support
Plug and Play Register Set
Power Supply Control
Watchdog timer compliant with Microsoft SHDG
LPC to SPI bridge for system BIOS support
Real Time Clock (RTC) module with external RTC interface
Baseboard Management Controller
IPMI 2.0 Compliant
Integrated 250 MHz 32-bit ARM9 processor
Six I2C SMBus Modules with Master-Slave support
Two independent 10/100 Ethernet Controllers with RMII support
LPC Master interface for non-volatile code storage
SPI Flash interface
Three UART for ICMB support
DDR2 16-bit up to 667 MHz memory interface
16 Mailbox Registers for communication between the host and the BMC
Watchdog timer
Three General Purpose Timers
Dedicated Real Time Clock for BMC
Up to 16 direct and 64 Serial GPIO ports
Ability to maintain text and graphics controller history
12 10-bit Analog to Digital Converters
Three Diode Inputs for Temperature measurements
36
Intel Order Number: E14960-009
Intel® Server Boards S3200SH/S3210SH TPS
Revision 1.8
