PCI Device, Embedded SCSI B
This option displays choices for configuring the features of embedded SCSI device B.
Entry
Onboard Ultra SCSI
Controller
Option ROM Scan
Enable Master
Latency Timer
PCI INTA IRQ Mapping
PCI Device, Embedded NIC
This option displays choices for configuring the features of the embedded Network Information
Card (NIC).
Entry
Onboard Ethernet
Controller
Option ROM Scan
Enable Master
Latency Timer
PCI INTA IRQ Mapping
Description
Controls whether or not the system activates the embedded PCI
device. The default setting is Enabled.
Initializes device expansion ROM. The default setting is Enabled.
Enables the selected device as a PCI bus master. The default setting
is Enabled.
Sets the minimum guaranteed time slice allotted for the bust master
in units of PCI bus clocks. The default setting is 0040H.
Devices can use hardware interrupts called IRQs. A PCI device
cannot use IRQs that are already in use by ISA devices. Use Auto
only if no ISA legacy cards are installed. The default setting is
Auto-select.
Description
Controls whether or not the system activates the embedded PCI
device. The default setting is Enabled.
Initializes device expansion ROM. The default setting is Enabled.
Enables the selected device as a PCI bus master. The default
setting is Enabled.
Sets the minimum guaranteed time slice allotted for the bust master
in units of PCI bus clocks. The default setting is 0040H.
Devices can use hardware interrupts called IRQs. A PCI device
cannot use IRQs that are already in use by ISA or EISA devices.
Use Auto only if no ISA or EISA legacy cards are installed. The
default setting is Auto-select.
