The base unit ports are labeled for easy reference. Refer to the following table as needed when
connecting cables to the base unit.
Connect the cable from this...
Monitors or monitor cables from cable
extension console
Mouse or mouse cable from cable
extension console
Keyboard or keyboard cable from cable
extension console
Modem, printer, or other serial devices
Printer or other parallel device
Universal Serial Bus devices
External Narrow Ultra SCSI devices
Network
Speakers or headphones
External audio device
Microphone
Game joystick or MIDI device
NOTE If an audio controller card is installed in the expansion slots, connect speakers,
headphone, microphone, and other external audio devices to the ports on the card.
See the audio controller documentation delivered with the system for more
information.
...To this port Port Description
Video Out ports on the graphics
controller cards
Mouse port
Keyboard port
Serial (COM) ports 1 and 2
1 2
Parallel (LPT) port
Universal Serial Bus ports
Narrow Ultra SCSI port
Ethernet port
Audio Line Out port for on-board
audio controller; not used if an
audio controller card is in the
expansion slots
Audio Line In port for on-board
audio controller; not used if an
audio controller card is in the
expansion slots
Microphone port for on-board
audio controller; not used if an
audio controller card is in the
expansion slots
MIDI/Game port
