Figure 10 Sample configuration—after configuring management and data ports
NOTE:
Due to the limited screen size, information for the management and data ports associated with the
controller in slot 2 are not shown in
Figure
10.
Configuring hard drives
Configuring hard drives includes two steps:
• Creating arrays
• Creating logical drives
NOTE:
For more information on configuring the storage, see
"Storage
overview" on page 85.
38
Configure
