5.
Enter the settings for the management port.
NOTE:
• Port State must be
disabled, you must use the Command Line Interface (CLI) to re-enable it. (For more
information, see the Command Line Interface user guide.)
• Assign a Host Name to the storage system (default: chassis serial number). HP
recommends changing this to a more helpful user-defined value.
• Port Name MA0 is the default management port. Although other ports can be
configured as the primary management port, HP recommends configuring and using
the default.
• To control the path of management traffic to and from the array controller and to
add one level of system security, HP recommends assigning a static IP address to the
management port that is in a different LAN segment than the data ports. To assign
a static IP address, expand the DHCP Setting drop-down box and change the setting
to Disabled. The page expands (shown), showing the currently assigned IP address.
Change this to the address you want to use for management traffic. After changing the
IP address, you may need to re-connect to the SMU using the newly assigned IP address.
• By default, VLAN ID is 0, meaning that traffic flowing from the port to the switch will be
untagged. To assign a VLAN for this port to use, enter its value. VLANs are set up on
the switch, and are used as one method of controlling access to the storage system.
IMPORTANT:
For dual-controller configurations, repeat these steps to configure the management port on the other
controller.
• The default management port for controller A is MA0.
• The default management port for controller B is MB0.
Configuring data ports
Configuring each data port includes two steps:
• Assigning one or more IP addresses to the port
• Assigning one or more TCP portals to each IP address
IMPORTANT:
Configure all data ports you plan to use, including ports on the Ethernet iSCSI module associated
with the controller in slot 2, if installed.
Enabled
(default) to use the SMU. If the management port state was
(Step 1).
(Step 4).
