Using the PC Card Sockets

The PC cards can expand the capabilities of the DeskNote computer. Your
DeskNote is equipped with two PC card sockets that accommodate one Type
III card or two Type II cards. These sockets support both PCMCIA standard
release 2.0 cards and 32-bits CardBus (PC card 95) cards, and so on. PC
cards can be LAN, fax/modem, communication devices, or expanded memory
ones. These PC card sockets can accept either 3.3V or 5V PC cards.
The lower socket named socket A is capable of ZV (Zoomed Video), which
allows a direct connection between a PC card and video devices that enables
high quality video playback (Figure 2-20).

Inserting the PC Cards

1. Open the access door of the PC card sockets (Figure 2-18).
2. Align the PC card with the appropriate socket and push it in firmly until it
locks into place.
Figure 2-18 Figure 2-19
