Attaching an External Monitor (CRT)

The computer is capable of displaying not only on the internal LCD, but also
on an external XGA display monitor. Simultaneous display on LCD and
External monitor is available. You may enter the System Configuration Utility
(SCU) to select the appropriate parameters or use the Fn + F6 keys (refer to
Chapter 2, Using Hot Keys) to change the display setting.
To connect an External Monitor, follow these steps:
1. Turn the system power off.
2. Connect the cable to the CRT port on the rear panel of the DeskNote
Computer.
3. Tighten the screws to fasten the cable to the CRT port.
4. Insert the other end of the cable to the external monitor.
5. Turn on the DeskNote Computer.
Figure 2-27
