EUROCOM DeskNote 2100P User Manual page 41

CPU Cover
Upgrading Processor Module 2100C
Heat Sink and Fan
Replacing Processor Module
1. Remove all power sources (AC power and battery).
2. Turn the Notebook over.
Processor Module
3. Remove the CPU cover.
4. Remove the screws that fasten the heat sink mounted on the Processor
Module.
5. Carefully use the CPU removing tool to detach the Processor Module
from the mainboard.
Note:
Wait for the CPU to cool down before replace it.
Contract your dealer for the CPU tool to replace the CPU.
Figure 2-2
CPU Cover
Heat Sink
CPU Module
Chapter 3—BIOS Utilities 2-5
