L i n e s
See System Programming for
instructions.
For single-line telephone users, answering machines, fax machines, or any other
device connected to a 012 or 008 OPT module or an MFM consider assigning
additional prime lines
any outside lines connected directly to the control unit, including special-
purpose lines
Single-line telephones can be programmed to select only the prime line (the
user cannot make inside calls or use system features) or to select the
intercom button followed by the prime line or outside line (the user can place
and receive inside calls and use system features).
Note: For adjuncts connected using an MFM, it's recommended that you
change the button 2 assignment to Intercom Originate Only and remove the
button 3 assignment (in both Key and Behind Switch modes).
Planning Form Instructions
Complete the "Button Diagram" section of each copy of Forms 4a, 4b (front
and back), 4c, and 5b (back only).
Note: The button diagrams for DLCs (the back of Form 5a and the front of
Form 5b) will be completed later.
To leave the factory-set assignments:
1 .
For multiline telephones in the Key Mode, fill in the telephone numbers on
buttons 3 through 10. For future reference, also record the line numbers.
(Refer to Form 2c).
2 .
For multiline telephones in the Behind Switch Mode, fill in the extension
number of the prime line on the button numbered "3".
To change the factory set assignments:
1 .
Show the type of intercom buttons on buttons 1 through 10 by writing
"Icom, Voice", "Icom Ring", or "Icom Originate Only".
2 .
Fill in the telephone numbers (or prime-line extension numbers) to be
assigned or changed. Start with the button numbered "3" and for future
reference, record the line numbers on the diagram. (Refer to Form 2c).
3 .
Assign Loudspeaker Page buttons by selecting the button and writing
"Page" on it.
3-41
Line Assignment
