Modifications
Step 5
See Chapter 3, "Line Connections" and
"Line Options."
See Chapter 4, "Labeling."
See Chapter 3, "Line Assignment."
See Chapter 4, "Remote Call Forward."
5-4
Adding to the System
Placing additional modules in the control unit calls for a recalculation of unit
loads. See System Reference for instructions.
If the control unit has an available slot to the right, and the guidelines permit
placement there, skip to step 5.
If you must rearrange existing modules to accommodate the new one, skip to
step 6.
Revise or complete the required Key System Planning Form(s) according to the
directions shown in Tables 5-2 through 5-4.
Table 5-2

Adding New Lines

If adding
New lines
Loop-start
DS1 facility
Tie trunk
If making more additions to the system, continue to the Table 5-3. When
planning is complete, continue to Chapter 3 of System Programming.
Complete
All columns of Form 2c, System
Numbering — Line Jacks
All columns of Form 2c, System
Numbering — Line Jacks, and
Form 3c, Outside Lines — DS1
Facility (100D Module)
All columns of Form 2c, System
Numbering — Line Jacks
Form 3d, Outside Lines — Tie
Consider revisions to outside
lines forms:
3a, Remote Access
Consider revisions to feature
form:
8a, Label Form — Lines
Button Diagram on appropriate
copies of Forms 4a through 5b
If personal line is assigned,
consider Remote Call Forward
