AT&T MERLIN LEGEND Key System Planning page 47

Control Unit
Jacks for Tip/Ring
Equipment and
Applications
See System Reference for more
information on applications.
Use these instructions only if the system includes 012 or 008 OPT modules.
Assign the basic telephone jacks on the 012 or 008 OPT modules to any tip/ring
equipment such as single-line telephones, fax machines, or answering
machines. Tip/ring equipment connects directly to an outside line and works on
a single pair of wires. When connected to a 008 OPT module, the tip/ring
equipment can be located off-premises.
Several optional applications, if used with the system, require a basic jack on a
012 module: MERLIN MAIL Voice Messaging System, MERLIN Attendant,
AUDIX Voice Power — lS II, and Integrated Voice Power Automated Attendant
— IS Il.
Up to four applications can be connected to the system using the same 012
module. If there are four applications, the module must be used exclusively
for this equipment If you have fewer than four applications connected to an
012 module, some tip/ring devices also can be connected. If possible, the
module should be used only for the application equipment.
Note: The applications discussed here do not work properly with 012 module
manufactured for older MERLIN® II systems. These applications must be
connected to 012 modules with the code 517C13 or 517D13 on the label on the
top of the module. Modules with the code 517A13 or 517B13 can be used only
to connect single-line telephones and do not provide the disconnect signal
required by answering machines and applications.
Planning Form Instructions
On Form 2a, mark the station jack assignments on the 012 and 008 OPT
m o d u l e s .
1.
In the "Jack Type" column, make sure there is a "B" checked next to the
logical ID for each basic telephone jack.
2 . In the "Person, Location, or Function" column, identify each tip/ring device
by person or location, and by type, such as single - line telephone, fax, or
answering machine.
3.
If the system includes optional applications indicate the type of
application in the "Person, Location, or Function" column:
Write "Mail" to indicate MERLIN MAIL Voice Messaging System.
Write "MERLIN A" to indiccate MERLIN LEGEND Attendant.
Write "AVP" to indicate AUDIX Voice Power — IS II.
Write "IVP - AA" to indicate Integrated Voice Power Automated
Attendant — IS II.
2-17
System Numbering
