Microphone Operation; Remote Call Forward - AT&T MERLIN LEGEND Key System Planning

Features

Microphone Operation

Remote Call Forward

See "Coverage" later in this chapter.
The microphone on MLX telephones and analog multiline telephones allows
users to have conversations through a speakerphone without lifting the handset.
You can disable the microphone on MLX telephones (but not on analog multiline
telephones) in areas in which use of the speakerphone is disruptive.
Planning Form Instructions
Under the "Microphone Operation" heading on Forms 4b and 5b:
1.
Check "Enable" to keep factory setting.
2.
Check "Disable" to prevent speakerphone use.
When the system is set up, it does not allow users to forward calls to outside
numbers. Remote Call Forward provides this feature for selected telephones;
for example, for users who often work away from the office. Calls forwarded to
locations outside the system may vary in transmission quality.
If the telephone has a personal line assigned, you can specify that incoming
calls on that line also can be forwarded to an outside number by assigning the
telephone as the principal user of the personal line.
Note: When a principal user is assigned, calls received on the personal line are
also sent to individual or group coverage receivers unless the personal line
button is set for no ring.
Planning Form Instructions
Under the "Remote Call Forward" heading on Forms 4a through 5b:
1.
Check "Not Allowed" to keep the factory setting.
2.
Check "Allowed" to provide Remote Call Forward.
Under the "Principal User of Personal Line" heading:
3.
Write the line number
you want the person to forward calls on the personal line to a remote
number. (Refer to Key System Form 2c, System Numbering — Line
Jacks).
and telephone number in the spaces provided if
Telephone Features
4-3
