AT&T MERLIN LEGEND Key System Planning page 91

Lines
Telephones
See Chapter 4 of System Reference for
additional information on modes and
line assignments.
Planning Form Instructions
4 .
Identify the equipment at each station (Refer to the Floor Plan).
Check the box that describes the ltelephone, console module, or type of
tip/ring equipment.
Check the box under "Adjuncts" that describes the adjuncts at the
s t a t i o n .
Note: Checking the "Data Terminal" box is informational only, See the
Data Guide.
The line buttons you can assign to telephones or adjuncts connected through an
MLX telephone using an MFM are:
Key and Behind Switch Modes
Key Mode only
Behind Switch Mode only
Key and Behind Switch Modes
Intercom Ring button - used to make and receive inside and outside calls.
When used to make inside calls, the called person hears one long ring to
indicate an inside call. The system automatically assigns this type of button
to all telephones.
Intercom Voice button - used to make and receive inside and outside calls.
When used to make inside calls, the called person hears the caller's voice.
The
system automatically assigns this type of button to all multiline
telephones and MFMs.
Intercom Originate Only button - used only to make inside and outside
calls. Calls are not received on this button, which ensures that the user
always has a button available to make calls. The button can be set to either
voice or ring operation for inside calls.
Loudspeaker Page button - used to make announcements over an optional
loudspeaker paging system. To make a loudspeaker announcement, the
user simply selects the Loudspeaker Page button, then speaks into the
handset. The user does not need to dial the extension number for the
loudspeaker paging system.
Key Mode Only
Personal Line button - used to dedicate an outside line for use by particular
telephones in the system. The Personal Line button is used to make and receive
only outside calls and the line can appear on more than one telephone (up to a
maximum of 64 stations).
3-37
Line Assignment
