Features

Fax Message Waiting Receiver and Threshold

4-4
Telephone Features
Use these instructions only if the system has fax machines connected
directly to the control unit via a 008 OPT or 012 module or connected to an
MLX telephone using a Multi-Function Module (MFM). These instructions are
not applicable to fax machines connected to an analog multiline telephone using
a General Purpose Adaptor (GPA).
Fax Message Waiting Receiver allows you to designate from one to four
telephones to receive message-waiting indications when a fax is received on a
specific fax machine. Fax machines can only send message-waiting indications;
they cannot receive message-waiting indications from other fax machines.
You can specify the Fax Message Threshold, which is the length of time
(0-30 seconds) before the system assumes a fax has arrived and sends the
message-waiting indication. The factory setting is 10 seconds.
Planning Form Instructions
For Fax machines connected to a 008 OPT or 012 Module, use Key System
Form 4c, Tip/Ring Equipment.
For Fax machines connected to an MLX telephone using MFM, use the
back of Key System Form 4b, Digital/ISDN (MLX) Telephone or K e y
System Form5b, Direct-Line Console (DLC) — Digital/ISDN.
In the "Fax Machine Features" section, under the "Fax Machine Receiver"
heading:
1.
Check "No" if you are not assigning a receiver and continue to the
"Operator Features" instructions.
2.
Check the second box to assign a Message Waiting Receiver. Write the
extension number of the telephone acting as the receiver in the space
provided. (Refer to Form 2a, System Numbering — Station Jacks).
Under the "Fax Message Threshold" heading:
3.
Check "10 seconds" to keep the factory set threshold.
4.
Check the second box to change the factory set threshold. Write the
number of seconds in the space provided.
Locate copies of Forms 4a through 5b that describe specific telephone(s)
designated as receiver(s) of Fax message-waiting indications.
Under the "Message-Waiting Receiver" heading:
5 .
Write the extension number of the Fax machine that sends a message
waiting indication to the telephone.
Note: You will fill in the rest of the optional telephone features later.
