Lines
Class of Restriction
See Chapter 4 for information on
Allowed and Disallowed Lists.
Planning Form Instructions—Continued
2.
Under the heading "Automatic Callback" at the top of Form 3a:
Check "Disable" if you do not want remote callers to use this feature.
Check "Enable" to allow this feature to remote callers.
3. Under the heading "Barrier Codes for Tie Trunks":
Check "Yes" if you plan to assign barrier codes to these lines.
Check "No" if no barrier codes are planned.
4. For "Barrier Codes for Non-Tie Lines":
Check "Yes" if you plan to assign barrier codes.
Check "No" if no barrier codes are planned.
For all lines to which you are assigning Remote Access:
5. Transfer the information from Key System Form 2c, System Numbering
— Line Jacks to Form 3a.
Write the logical ID and the line number in the applicable column.
Check either the "Tie Trunk" or "Non-Tie Line" column.
Complete the "Line Type and Description" column. Include the different
bands (calling areas) of WATS lines and different destinations for FX
lines.
6. Check the "Shared" column (to indicate shared access) or the
"Dedicated" column (to indicate dedicated access for the lines.
The class of restriction is assigned to all lines with Remote Access. If barrier
codes are planned, you also must assign the class of restriction for each barrier
code.
Make the following decisions regarding class of restriction:
Restriction. The setting determines whether users can make local and/or toll
calls (the factory setting is for inside calls only).
You can change the setting to unrestricted (the users can make local and toll
outside calls) or restricted (the user can make only local outside calls).
Allowed List Assignment When users are restricted from making local
and/or toll calls, you can assign up to eight Allowed Lists that allow restricted
users to call specific numbers (local or toll).
Disallowed List Assingnment When users are not restricted from making
calls, you can assign a Disallowed List that prevents them from dialing
specific numbers on the list.
3-11
Line Options
