Lines

Line Assignment

Follow the instructions in the Data Guide
to assign lines to data stations.
3-36
Line Assignment
Use these instructions to assign lines to telephones and direct-line
consoles.
There are five different forms for recording line assignments. Prepare one copy
of the appropriate form for each station.
Key System Form 4a, Analog Multiline Telephone
Key System Form 4b, Digital/lSDN (MLX) Telephone the (front for the
telephone and the back for an adjunct connected using a Multi-Function
Module)
Key System Form 4c, Tip/Ring Equipment
Key System Form 5a, Direct-Line Console (DLC)—Analog
Key System Form 5b, Direct-Line Console (DLC)—Digital/lSDN (the front for
the telephone and the back for an adjunct connected-using a Multi-Function
Module)
Planning Form Instructions
On the front of Form 4a through 5b:
1 .
Transfer the user identification from Key System Form 2a, System
Numbering — Station Jacks to each copy of all telephone forms.
Write the logical ID in the "Logical ID" space.
Write the extension number in the "Extension No." space.
Write the name of the person or location of the equipment in the
"Person or Location" space.
On the Reverse side of Form 4a and Form 5b:
2 .
Fill in the user identification from the Key System Form 2b, System
Numbering — Digital/ISDN Station Adjuncts for any adjuncts
connected to an MLX telephone using an MFM.
Write the extension number in the "Extension No." space.
Write the name of the person or the location of the equipment in the
"Person or Location" space.
3 . Locate any "voice/voice" or "voice/data" entries in the "Person or Location"
column of Form 2a. Under the "Station Jack Pair" heading on Form 4a
and 5a:
Check the "Voice Announce to Busy" box or the "Simultaneous Voice
and Data" box to indicate the type of station jack pairs.
Enter the logical ID and extension number under the "Even-numbered
jack" heading.
