Set Fc; Set Features - HP StorageWorks 6100 - Enterprise Virtual Array User Manual

Chassis Name (Max = 64 characters) [ ] rack 14
All attribute values that have been changed will now be saved.

Set FC

Configures an FC port.
Authority
Syntax
Keywords
Example:
MPX200 <1>(admin) #> set fc
A list of attributes with formatting and current values will
follow.
Enter a new value or simply press the ENTER key to accept the
current value. If you wish to terminate this process before
reaching the end of the list press 'q' or 'Q' and the ENTER key to
do so.
WARNING:
The following command might cause a loss of connections to both
ports.
Configuring FC Port: 1
-------------------------
Link Rate (0=Auto, 1=1Gb, 2=2Gb) [Auto ]
Frame Size (0=512B, 1=1024B, 2=2048B) [2048 ]
Execution Throttle (Min=16, Max=256) [64 ]
Programmed Connection Option:
(0=Loop Only, 1=P2P Only, 2=Loop Pref) [Loop Pref ]
All attribute values for Port 1 that have been changed will now be
saved.
Configuring FC Port: 2
-------------------------
Link Rate (0=Auto, 1=1Gb, 2=2Gb) [Auto ]
Frame Size (0=512B, 1=1024B, 2=2048B) [2048 ]
Execution Throttle (Min=16, Max=256) [64 ]
Programmed Connection Option:
(0=Loop Only, 1=P2P Only, 2=Loop Pref) [Loop Pref ]
All attribute values for Port 2 that have been changed will now be
saved.

Set features

Applies license keys to the router. The date and time must be set on the router before applying a new
key.
NOTE:
This option is not currently supported. It will be supported in a future release.
Authority
Admin session
set fc [<PORT_NUM>]
The number of the FC port to be configured.
[ < P O R T _ N U M > ]
Admin session
MPX200 Multifunction Router 159
