Chapter 5
To expand a view that has been collapsed (physical or logical drives, or hot
spares are hidden):
Click the + sign in the yellow diamond.
To display the properties of a logical drive:
Double-click the logical drive in the Logical Devices box.
To display the properties of a physical drive:
Double-click the physical drive in the Physical Devices box.
To change a logical drive:
1. Click the Back button to back up to the previous screen.
2. Delete the last logical drive defined (accepted) by clicking the Undo
button. Keep clicking Undo until you have removed the logical drive you
want to change.
3. Configure the logical drives again or click Back to back up and change
array definitions.
To correct the assignment of physical drives:
1. Undo any logical drives that are defined on the array by clicking Back,
then clicking Undo as necessary to delete the last logical drive.
2. Click the Back button to go to the Array Definition screen.
3. Select the array to be reclaimed, and click the Reclaim button.
4. Configure the physical drives and logical drives again.
To start the configuration over again:
Click the Cancel button.
To accept the final configuration:
Click the Finish button on the Configuration Preview screen.
To save your configuration and initialize logical drives:
1. Click OK at the message asking if you want to save the configuration.
A Writing Configuration message appears briefly, indicating that the
configuration information is being written to the adapter's NVRAM. This
is not a binary file that can be loaded to restore the configuration.
Installation and Configuration
65
