Chapter 5
NOTE To check the capacity of a physical drive, double-click on it to
display its properties.

Select Wizard

NOTE If any physical drives have been moved, added, removed,
changed, or changed in state since HP NetRAID Assistant was
started, rescan the drives by choosing the Adapter menu and
then selecting the Rescan option.
To launch the HP NetRAID Assistant Wizard:
1. Select the Configuration menu.
2. Choose the Wizard. The Wizard starting window is displayed, as shown
in Figure 5-6, with a choice of Custom and Automatic configuration
modes.
Figure 5-6. HP NetRAID Assistant Wizard Starting Window
Installation and Configuration
57
