HP Rack Storage/12FC & HP Rack Storage/12
Introduction
This document defines the supported HP NetServer LP2000r configurations using the HP Rack Storage/12FC
and Microsoft Cluster Server and one or two HP Rack Storage/12s. These configurations minimize single
points of failure (SPOF, SPOFless
supported by both Hewlett-Packard and Microsoft is defined, as are other guidelines to assist you in
configuring your clustered NetServers. This guide is prescriptive; it describes the configurations supported by
HP. Any deviance to these configurations can result in an inoperative cluster or an operating cluster with
degraded performance, hidden SPOFs, etc., and therefore will not be supported by HP.
What's Defined in a Racked Cluster
Cluster
Type of SPUs
Number of nodes
Shared Storage
LANs:
Client LAN
Intra-cluster
(Heartbeat) LAN
Power source
1
For more information about configuring a SPOFless cluster, refer to the HP white paper, High Availability
MSCS Cluster Solution on the HP NetServers, HA Planning website.
HP NetServer LP2000r
with
Cluster Configuration Guide
21 March 2001
(see
Versions
at the end of this document)
1
) and provide extended availability. The specific configuration certified and
Cluster
SPUs
Local and Shared Storage
Intra-cluster and Client LANs
Shared Storage Cabling
HP NetServer LP2000r
Each node must be the same SPU, but may have different clock speeds,
main memory sizes, cache sizes, and number of CPUs.
2
HP Rack Storage/12FC with two FCArray Cards, HP disks, and an HP
D8602B HBA in each server. See
Any that is HP and Microsoft approved. See
For a SPOFless cluster, two D5013B NICs configured with AFT is
recommended (Add one NIC and pair with embedded).
Embedded NIC with crossover cable. See
Direct from power mains, power conditioner or uninterruptible power
Shared Storage
Client LAN
Intra-cluster LAN
1
below.
below.
below.

Advertising

   Related Manuals for HP D7171A - NetServer - LPr

   Summary of Contents for HP D7171A - NetServer - LPr

  • Page 1

    ) and provide extended availability. The specific configuration certified and supported by both Hewlett-Packard and Microsoft is defined, as are other guidelines to assist you in configuring your clustered NetServers. This guide is prescriptive; it describes the configurations supported by HP.

  • Page 2

    supply (UPS) using any power conditioner or UPS. Redundant power distribution units (PDU’ s) are strongly recommended. System software: Navigator version L.20.00 or later Operating System Microsoft Windows NT Server 4.0, Enterprise Edition Service Pack SP6a or later Model HP NetServer LP2000r Clock speed 1 GHz No.

  • Page 3

    Cabinet RAID arrays Not more than 8 physical drives per logical array and not more than 8 LUNs are permitted per Rack Storage/12FC and Rack Storage/12 combination in a cluster. No. of cabinets FC Array Cards Model D5990A No. of cards/cabinet 2 - Duplex (Requires installing a second card in the Rack Storage/12FC.) Firmware...

  • Page 4

    NIC: Model Embedded Any that is on both the HP Tested Products List and the Microsoft Hardware Compatibility List. Driver Hptxnt.sys 4.02.35 or later Vendor supported driver. NOTE If the Client and Intra- cluster LANs are the same model, the Client LAN must use the same driver as the Intra-cluster LAN.

  • Page 5

    Fibre-channel HBA with GBIC Fibre-channel Hub with GBICs. NOTES 1. The HBA and NICs are depicted in PCI slots as follows: NetRAID-1M in P1 D8602B in P2 D5013B in P3 2. The bottom two shared storage devices are SCSI HP Rack Storage/12s and are optional to the cluster configuration.

  • Page 6

    Power Cabling to Separate Power Circuits (For SPOFless with 2 hubs, connect second hub to PDU that first hub is not attached to)

  • Page 7

    Fibre-channel HBA with GBIC Fibre-channel Hub with GBICs Each copper cable goes to Port ‘ x’ on the RS/12FCarray controllers. NOTES 1. The local array controller, HBA and NICs are depicted in PCI slots as follows: NetRAID-1M in P1 HBA in slot P2 D5013B in P3 2.

  • Page 8

    Fibre-channel HBA with GBIC For a direct connection, copper cable goes to Port ‘ x’ on first RS/12FC array controller. NOTES 1. The local array controller HBA and NICs are depicted installed in PCI slots as follows NetRAID-1M in P1 HBA in P2 D5013B in P3 2.

  • Page 9

    Versions 21 March 2001 Initial release...
