Insert The Hp Netraid-3Si Adapter And Recreate The Configuration - HP D5970A - NetServer - LCII Installation And Configuration Manual

Chapter 8
2. Use the HP NetServer Navigator CD-ROM to prepare the diskettes you
need to install the non-I
utility specific to your NOS. See Step J for complete instructions.
3. Uninstall the old HP NetRAID drivers and install the new HP NetRAID
drivers as described in Step K.
4. Install the NOS-specific configuration utility as described in Step L.
Insert the HP NetRAID-3Si Adapter and Recreate
the Configuration
CAUTION All HP NetRAID Series adapters are sensitive to static
electricity and can easily be damaged by improper handling.
Using a grounding strap is recommended. Read the following
information carefully before you handle the accessory:
To remove any HP NetRAID Series adapter and replace it with an HP
NetRAID-3Si adapter, do the following:
1. Turn off the system, unplug the power cord from the system, remove the
HP NetServer cover, and disconnect the SCSI cables from the existing HP
NetRAID Series adapter. Remove the existing adapter, and place it on a
grounding mat or other antistatic surface. If you have removed an HP
NetRAID or HP NetRAID-3Si adapter, disconnect the Battery Backup
Unit by unplugging the connector shown in Figures 5-2 and 5-3.
94
Upgrading to an HP NetRAID-3Si Adapter
O drivers and the HP NetRAID configuration
2
Leave the new HP NetRAID-3Si adapter in the antistatic
bag until you are ready to install it.
If possible, use an antistatic wrist strap and antistatic
grounding mat.
Before you touch the existing adapter, touch a grounded,
unpainted metal surface on the system to discharge static
electricity.
When removing or installing an HP NetRAID or
HP NetRAID-3Si adapter, do not allow the adapter or the
Battery Backup Unit to touch any part of the HP
NetServer, or any other conductive surface (except an
antistatic mat), because that could cause a short in the
Battery Backup Unit.
