Hard drive

NOTE:
All hard drive spare part kits include a hard drive bracket.
Description
250-GB, 5400-rpm
200-GB, 4200-rpm
160-GB, 5400-rpm
120-GB, 7200-rpm
120-GB, 5400-rpm
100-GB, 7200-rpm
Before removing the hard drive, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the hard drive:
Loosen the six black Phillips PM2.0×5.0 captive screws (1) that secure the hard drive bay cover to
1.
the computer.
Lift the rear edge of the hard drive bay cover (2), swing it forward, and remove the cover. The hard
2.
drive bay cover is included in the Plastics Kit, spare part number 448171-001.
Loosen the Phillips PM2.5×12.0 screw (1) that secures each hard drive to the computer.
3.
Disconnect the hard drives (2) from the system board by sliding the hard drives away from the hard
4.
drive connectors.
Battery on page
38).
Spare part number
454605-001
448155-001
448154-001
448152-001
448153-001
452313-001
Component replacement procedures
45
