Processor fan

Description
Processor fan
NOTE:
To properly ventilate the computer, allow at least a 7.6-cm (3-inch) clearance on the left and
right sides and rear panel of the computer. The computer uses two electric fans for ventilation. The fans
are controlled by a temperature sensor and are designed to turn on automatically when high temperature
conditions exist. These conditions are affected by high external temperatures, system power consumption,
power management/battery conservation configurations, battery fast charging, and software
requirements. Exhaust air is displaced through the ventilation grills located on the computer rear panel.
Before removing the processor fan, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the following components:
5.
Hard drive (see
a.
Optical drive (see
b.
Keyboard (see
c.
Hinge cover (see
d.
Rear cover (see
e.
Top cover (see
f.
Subwoofer (see
g.
Remove the processor fan:
Disconnect the processor fan cable (1) from the system board.
1.
Remove the two Phillips PM2.5×8.0 screws (2) that secure the processor fan to the base enclosure.
2.
Battery on page
38).
Hard drive on page
45)
Optical drive on page
Keyboard on page
54)
Hinge cover on page
Rear cover on page
57)
Top cover on page
59)
Subwoofer on page
72)
52)
56)
Component replacement procedures
Spare part number
448162-001
75
