Hinge cover (see
d.
Rear cover (see
e.
Top cover (see
f.
Remove the subwoofer:
Disconnect the subwoofer cable (1) from the system board.
1.
Remove the three Phillips PM2.5×8.0 screws (2) that secure subwoofer the to the base enclosure.
2.
Remove the subwoofer (3).
3.
CAUTION:
subwoofer screws can result in damage to the subwoofer grommets (4), which can cause a decrease
in the subwoofer performance.
Reverse this procedure to install the subwoofer.

Video connector board

Description
Video connector board (includes cable)
Before removing the audio connector board, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Hinge cover on page
Rear cover on page
Top cover on page
When installing the subwoofer, do not overtighten the screws. Overtightening the
56)
57)
59)
Component replacement procedures
Spare part number
452321-001
73
