Item
Description
Display Rubber Pad Kit (not illustrated)
Display Screw Kit (not illustrated)
Plastics Kit
Item
Description
Plastics Kit
(1)
WLAN module compartment cover (includes 1 captive screw, secured by a C-clip)
(2)
ExpressCard slot bezel
(3)
TV tuner module compartment cover (includes 1 captive screw, secured by a C-clip)
(4)
Memory module compartment cover (includes 2 captive screws, secured by C-clips)
(5)
Hard drive bay cover (includes 2 captive screws, secured by C-clips)
24
Chapter 3 Illustrated parts catalog
Spare part number
454595-001
452309-001
Spare part number
448171-001
