Rear cover (see
e.
Top cover (see
f.
Remove the power connector LED board:
Disconnect the power connector LED board (1) from the system board.
1.
Remove the power connector LED board (2).
2.
Reverse this procedure to install the power connector LED board.
Rear USB board
Description
Rear USB board (includes cable)
Before removing the rear USB board, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the following components:
5.
Hard drive (see
a.
Optical drive (see
b.
Keyboard (see
c.
Hinge cover (see
d.
Rear cover on page
57)
Top cover on page
59)
Battery on page
38).
Hard drive on page
45)
Optical drive on page
Keyboard on page
54)
Hinge cover on page
52)
56)
Component replacement procedures
Spare part number
452315-001
71
