Preparing and Installing the 9A426-01 Module

The Module's Physical Layout

The 9A426-01 Module has two major circuit boards on which components are

attached (see Figure 2-1). The module's base-level circuit board is known as the

motherboard. The module's second-level circuit board is known as the

daughterboard. The removable daughterboard attaches to the motherboard's

connectors and standoffs. Both the motherboard and the daughterboard contain

components that are accessible to the user.

motherboard

Figure 2-1. The 9A426-01 Module's two major circuit boards

2-2

daughterboard
