LANVIEW LEDs

The front panel LANVIEW LEDs indicate the status of the module and aid
in troubleshooting the module. The LANVIEW LEDs of the 9A426-01
Module are shown in Figure 4-1.
SMB
INB Receive
FNB Receive
ATM Receive
Figure 4-1. The LANVIEW LEDs of the 9A426-01 Module
ATM
9A426-01
SMB CPU
INB
FNB
INB Transmit
FNB Transmit
A
ATM Transmit
T
M
1
Chapter 4
CPU
4-1
