The status of the INB Transmit LED is listed in Table 4-3.
LED Color
Green (Flashing)
Yellow (Flashing)
Red
Red (Flashing)
Off
The status of the FNB Receive LED is listed in Table 4-4.
LED Color
Green
Yellow (Flashing)
Red
Red (Flashing)
Off
The status of the FNB Transmit LED is listed in Table 4-5.
LED Color
Green (Flashing)
Yellow (Flashing)
Red
Red (Flashing)
Off
Table 4-3. INB Transmit LED
Activity, port is enabled
Port is in standby mode
Port is disabled
Fault or error exists
No activity, port is enabled
Table 4-4. FNB Receive LED
Link exists, no activity, port is enabled
Link exists, activity, port is enabled
No link, port is disabled
Link exists, port is disabled
No link, no activity, port is enabled
Table 4-5. FNB Transmit LED
Activity, port is enabled
Port is in standby mode
Port is disabled
Fault or error exists
No activity, port is enabled
State
State
State
4-3
