- Page 1 SmartSwitch 9000 9E106-06 Local Management Appendix 9032179-01...
-
Page 3: Module Interfaces
Appendix 9E106-06 Module Specific Information Introduction This appendix contains local management information that is specific to the 9E106-06 Ethernet Module. Module Interfaces The 9E106-06 Ethernet Module has 9 interfaces. Table 1 lists the identifying number, name, and description of each interface. Table 1. - Page 4 9E106-06 Module Specific Information FNB Resource Configuration Codes The 9E106-06 Ethernet Module provides connectivity between seven interfaces: the six front panel Ethernet interfaces and the FDDI rings on the backplane (FNB- 1 or FNB-2). The FNB Resource Configuration Screen allows you to connect the module’s front panel Ethernet interfaces to one of the chassis’...
-
Page 5: Interface Statistics Screen
9E106-06 Module Specific Information Interface Statistics Screen The 9E106-06 Interface Statistics Screen (Figure 1),, displays a variety of statistical information about the module. INTERFACE STATISTICS INTERFACE: 3 INTERFACE: 4 INTERFACE: 5 IN OCTETS: 8650 IN UNICAST PKTS: IN NONUCAST PKTS: IN DISCARDS: IN ERRORS: OUT OCTETS:... -
Page 6: Interface Statistics Screen Fields
9E106-06 Module Specific Information Interface Statistics Screen Fields The following information briefly explains each Interface Statistics Screen field. INTERFACE (Toggle) Allows you to select the interface you want to monitor. IN OCTETS (Read-only) Displays the number of octets (bytes) received by this interface. IN UNICAST PKTS (Read-only) Displays the number of unicast packets (packets destined for one specific address) received by this interface. - Page 7 9E106-06 Module Specific Information OUT OCTETS (Read-only) Displays the number of octets (bytes) transmitted by this interface. OUT UNICAST PKTS (Read-only) Displays the number of unicast packets (packets destined for one specific address) transmitted by this interface. OUT NONUCAST PKTS (Read-only) Displays the number of non-unicast packets (multicast and broadcast packets, in other words, packets destined for more than one address) transmitted by this interface.
- Page 8 9E106-06 Module Specific Information Selecting Another Interface To select another interface: 1. Use the arrow keys to highlight any one of the INTERFACE fields at the top of the Interface Statistics Screen. 2. Press SHIFT and [=] or [-] until the desired value appears. 3.
-
Page 9: Port Redirect Function Screen
9E106-06 Module Specific Information Port Redirect Function Screen The 9E106-06 Port Redirect Function Screen (Figure 2),, allows you to set each one of the ports as a source or destination port. You can set a port to have one or more destination ports. -
Page 10: Port Redirect Function Screen Fields
9E106-06 Module Specific Information Port Redirect Function Screen Fields The following information briefly explains each Port Redirect Function Screen field. Source Port (Read-only) Displays the port number of the ports that are set as source ports. Destination Port (Read-only) Displays the port number of the ports that are set as destination ports. Source Port [ x] (Modifiable) Allows you to change a selected port [ x] to a source port. - Page 11 9E106-06 Module Specific Information 6. Use the Space Bar to select either the [ADD] or [DEL] option, then press the Enter key. This adds or deletes the port selections made in steps 2 through 4, and also updates the Source Port and Destination Port list. To redirect another port, repeat steps 1 through 6, then go to step 7 to save all the new settings at once.
- Page 12 9E106-06 Module Specific Information...
