Introduction
If the module's redundant link and primary link are two different physical ATM
NOTE switches, the module will receive a new ATM address.
Although the actual physical switch (from primary to redundant link) performed
by the module is nearly immediate, the amount of time required to re-establish
full communications varies according to factors associated with LANE 1.0
protocols and the performance/feature set of the user's LANE services, but is
typically less than one minute.
Management Information Base (MIB) Support
The 9A426-01 Module provides MIB support including:
• IETF AToM MIB,
• IETF FDDI MIB,
• IETF Bridge MIB, and
• a host of Cabletron Enterprise MIBs
LANVIEW LEDs
The 9A426-01 Module uses LANVIEW – Cabletron Systems built-in visual
diagnostic and status monitoring system. With LANVIEW LEDs, you can quickly
identify the device, port, and physical layer status at a glance.
1-4
