Preparing and Installing the 9A426-01 Module

Removing the daughterboard from the motherboard

Never expose the module's components to Electrostatic Discharge: Make sure you
have attached the module's disposable grounding strap to your wrist and always
WARNING
place the module on a non-conductive surface.
To remove the module's daughterboard from the motherboard:
1. Place the module (component side up) on a non-conductive, flat surface.
Position the module so that the module's front (faceplate) is to the left and the
module's back (backplane connectors) is to the right. The daughterboard
abuts the backplane connectors (see Figure 2-1).
2. Locate the daughterboard's nine securing screws (see Figure 2-9).
3. Use a phillips head screwdriver to remove the securing screws. Set the screws
aside.
4. Grasp the daughterboard and lift up.
5. Turn the daughterboard over to reveal its user-accessible components (see
Figure 2-10).
