Preparing and Installing the 9A426-01 Module
Installing the Module into the SmartSwitch 9000
Chassis
To install the 9A426-01 Module into the SmartSwitch 9000 chassis, follow the
steps below:
To insure proper data transmission from the 9A426-01 Module to the INB on the
NOTE SmartSwitch 9000 backplane, two INB Terminator Modules must be installed on
the rear of the SmartSwitch 9000 chassis. Refer to the INB Terminator Module
Installation Guide for information and installation procedure.
1. Remove the blank panel covering the slot in which the module is being
installed. If you are only installing one module, make sure the chassis' other
module slots are covered. This action ensures proper airflow and cooling.
2. Attach one end of the ESD wrist strap packaged with the SmartSwitch 9000
chassis to your wrist. Plug the other end into the ESD Wrist Strap Grounding
receptacle in the lower right corner of the SmartSwitch 9000 chassis shown in
Figure 2-11.
3. Grasp the module and slide it into the slot. Make sure that the module's
circuit card is between the card guides, as shown in Figure 2-11. Check both
the upper and lower tracks of the card. Take care that the module slides in
straight and engages the backplane connectors properly.
4. Lock down the top and bottom plastic tabs, as shown in Figure 2-11.
2-16
