- Page 1 SmartSwitch 9000 9E428-12/36 and 9E429-12/36 Local Management Appendix 9032034-01...
- Page 3 9E428-12/36 and 9E429-12/36 Module Specific Information Introduction This appendix contains local management information that is specific to the following Ethernet modules: • 9E428-12 (12 Ports, Multimode Fiber, ST connectors) • 9E428-36 (36 Ports, Multimode Fiber, ST connectors) • 9E429-12 (12 Ports, Single-Mode Fiber, ST connectors) •...
-
Page 4: Modifying Fields And User Privileges
9E428-12/36 and 9E429-12/36 Module Specific Information Modifying Fields and User Privileges To modify fields on these modules, you must have read-write or super-user privileges. If you have read-only privileges, you can view information; however, you cannot modify any fields. For more information about user privileges and community names, see the SmartSwitch 9000 Module Local Management User’s Guide. - Page 5 9E428-12/36 and 9E429-12/36 Module Specific Information Table 1. 9E428-36 and 9E429-36 Module Interface Codes (Continued) Interface Interface Number Name ENET13 ENET14 ENET15 ENET16 ENET17 ENET18 ENET19 ENET20 ENET21 ENET22 ENET23 ENET24 ENET25 ENET26 ENET27 ENET28 ENET29 ENET30 ENET31 ENET32 ENET33 ENET34 ENET35 ENET36...
- Page 6 9E428-12/36 and 9E429-12/36 Module Specific Information Full Duplex Configuration Screen The 9E428-12/36 and 9E429-12/36 Full Duplex Configuration Screen (Figure 1), displays the port number, operation mode, link status, and port status of the module’s ports (12 ports at a time). Module Name: 9E428-36 Slot Number: 9 PORT#...
-
Page 7: Full Duplex Configuration Screen Fields
Full Duplex Configuration Screen Fields The following information briefly explains each Full Duplex Configuration Screen field. OPERATION MODE (Modifiable) Indicates whether the specified port will transmit and receive data separately or simultaneously. You can set this field to one of the following values: •... - Page 8 9E428-12/36 and 9E429-12/36 Module Specific Information Displaying Information About Other Ports To display information about other ports: 1. Use the arrow keys to highlight one of the following fields (located at the bottom of the Full Duplex Configuration Screen): • [1-12] (for the first 12 ports) •...
-
Page 9: Switch Configuration Screen
Switch Configuration Screen The 9E428-12/36 and 9E429-12/36 Switch Configuration Screen (Figure 2), provides basic setup options for making a switch operational in your network. Module Name: 9E428-36 Slot Number: 9 Switch Address: Numbers of Ports: Port # SAVE Figure 2. 9E428-12/36 and 9E429-12/36 Switch Configuration Screen Port # refers to the following: NOTE •... - Page 10 9E428-12/36 and 9E429-12/36 Module Specific Information Switch Configuration Screen Fields The following information briefly explains each Switch Configuration Screen field. Type of STA (Toggle) Allows you to set the method that switches use to decide which switch is the controlling (Root) switch when two or more switches exist in parallel (Spanning Tree Algorithm).
- Page 11 Status (Toggle) Allows you to set the forwarding status of the listed interface (either ENABLED or DISABLED). Press the Space Bar to toggle to the desired value. Valid entries are: • ENABLED • DISABLED Displaying Other Ports To display other ports: 1.
-
Page 12: Port Statistics Screen
9E428-12/36 and 9E429-12/36 Module Specific Information Port Statistics Screen The 9E428-12/36 and 9E429-12/36 Port Statistics Screen (Figure 3), displays information and statistics about the module’s Ethernet ports. Module Name: 9E428-36 Slot Number: 9 PACKETS: TOTAL ERRORS: COLLISIONS: CRC/ALIGNMENT ERRORS: UNDERSIZE PACKETS: OVERSIZE PACKETS: FRAGMENTS: JABBERS:... -
Page 13: Port Statistics Screen Fields
9E428-12/36 and 9E429-12/36 Module Specific Information Port Statistics Screen Fields The following information briefly explains each Port Statistics Screen field. PORT # Indicates the current port for which statistics are displayed. OCTETS Displays the number of octets transmitted and received. PACKETS Displays the number of packets transmitted and received. - Page 14 9E428-12/36 and 9E429-12/36 Module Specific Information MULTICASTS Displays the number of multicasts received. LINK STATUS Indicates whether there is a physical connection from this port to another 10Base- FL device. One of the following values appears: • Link - There is a 10Base-FL link signal present; there is a valid physical connection from this port to another 10Base-FL device.
- Page 15 PORT # (Modifiable) Selects the port for which statistics are to be displayed. Displaying Statistics for Another Port To display statistics for another port: 1. Use the arrow keys to highlight the Port # field at the bottom of the screen. 2.
-
Page 16: System Resources Screen
9E428-12/36 and 9E429-12/36 Module Specific Information System Resources Screen The 9E428-12/36 and 9E429-12/36 System Resources Screen (Figure 4), displays information about current and available resources on the module. Device Name: 9E428-36 Slot #: 12 Flash Memory Installed: 4 Mb DRAM Installed: SRAM Installed: NVRAM Installed: PORT #: 1... -
Page 17: System Resources Screen Fields
9E428-12/36 and 9E429-12/36 Module Specific Information System Resources Screen Fields The following information briefly explains each System Resources Screen field. Flash Memory Installed/Available Displays the size of Flash Memory and indicates how many bytes are currently available. DRAM Installed/Available Displays the size of dynamic random access memory (DRAM) and indicates how many bytes are currently available. - Page 18 9E428-12/36 and 9E429-12/36 Module Specific Information...
