ProSafe 20-AP Wireless Controller WC7520 Reference Manual
To configure WLAN group assignments:
1. Select Configuration > WLAN Network. The WLAN Group Assignment screen
displays:
Figure 37.
The displayed settings are explained in
2. To assign an access point to a group, select the correct group from the Group Name
drop-down list.
3. Click Apply to save your settings.
Table 15. WLAN Group Assignment
Field
IP
MAC
Model
Name
Building
Floor
Status
Group Name
Table 15, WLAN Group Assignment
Description
The IP address of the access point.
The MAC address of the access point.
The model of the access point.
The name you specified for the access point.
The building in which the access point is located. See
and Floors on page 38 and
The floor on which the access point is located.
Floors on page 38 and Editing Access Point Information
The access point connectivity status.
• Connected: This indicates normal operation.
• Not Connected: The wireless controller cannot communicate with the access point
with the configured IP address.
The wireless controller tries to log in to managed access points every 1 minute. If the
error is temporary, the status automatically changed to connected. If the error is
prolonged, verify the access point's IP address and network connectivity.
Select the group name you want the access point to use. See
Point Groups on page 65.
Defining and Editing Buildings
Editing Access Point Information
Defining and Editing Buildings and
Chapter 6: Managing Access Point Groups
on page 67.
on page 51.
on page 51.
Configuring Access
