ProSafe 20-AP Wireless Controller WC7520 Reference Manual
Client VLANs
Each authenticated wireless user is placed into a VLAN that determines the user's DHCP
server, IP address, and layer 2 connection. Although you could place all authenticated
wireless users into the single VLAN that is specified in the basic security profile, the wireless
controller allows you to group wireless users into separate VLANs based on the wireless
SSID to differentiate access to network resources. For example, you might place authorized
employee users into one VLAN and itinerant users, such as contractors or guests, into a
separate VLAN. To use different VLANs, you must create different security profiles.
For information about how to configure regular VLANs, see
Profiles on page 83.
DHCP Server
The wireless controller can function as a DHCP server and assign IP addresses to both
wireless and wired devices that are connected to it. You can add up to 64 DHCP server
pools, each assigned to a different VLAN.
Client Authentication and Data Encryption
A user must authenticate to the WLAN to be able to access WLAN resources. The wireless
controller supports several types of security methods, including those that require an external
RADIUS or LDAP authentication server.
The encryption option that you can select depends upon the authentication method that you
have selected. The following table lists the authentication methods available, with their
corresponding encryption options.
Table 2. Authentication and Encryption Options
Authentication Method
Open system
Shared Key
Legacy 802.1x
WPA-PSK
WPA2-PSK
WPA-PSK and WPA2-PSK
WPA
WPA2
WPA and WPA2
For information about how to configure client authentication and data encryption, see
Managing Wireless Security Profiles
Encryption Option
64-bit, 128-bit, or 152-bit WEP
64-bit, 128-bit, or 152-bit WEP
WEP
TKIP or TKIP+AES
AES or TKIP+AES
TKIP+AES
TKIP or TKIP+AES
AES or TKIP+AES
TKIP+AES
on page 83.
Chapter 2: System Planning and Deployment Scenarios
Managing Wireless Security
Authentication Server
None
None
Internal authentication server or
external RADIUS server
None
None
None
Internal authentication server, external
RADIUS server, or external AD server
Internal authentication server, external
RADIUS server, or external AD server
Internal authentication server, external
RADIUS server, or external AD server
