ProSafe 20-AP Wireless Controller WC7520 Reference Manual
Note that the planning tool only provides default placement and shows the coverage area
for each access point.
6. Move the access points to optimize coverage in desired areas and avoid coverage in
unwanted areas based on the floor plan.
Colored circles around the access point symbols indicate the expected approximate
coverage of the individual access point, and the color of the circle represents the
expected quality of the signal strength: a darker color indicates signal overlap with nearby
access points.
Note: A red color indicates the strongest coverage area: better than -50 dBm
RSSI; an orange color better than -60 dBm; a yellow color better than -70 dBm;
and so on.
Moderate overlap is required for seamless roaming. No overlap will lead to
disconnections and dead spots
You can click an access point icon and drag it to manually reposition it to see how the
new location would affect the coverage. Click Cancel to undo any access point
repositioning changes.
Use the Zoom slider to increase or decrease the size of the map.
7. Click Save to save the location map, or click Back to return to the Planning Buildings
screen without savings changes to the location map.
Note: For each floor, you can save one location map only. When you
modify and save the location map, the previously saved location
map is overwritten.

Viewing and Managing Heat Maps for Deployed Plans

A heat map lets you view in realtime, by wireless frequency band, the signal strength and
wireless coverage for a building floor. The heat map shows the actual signal strengths that
each access point is detecting from neighbor access points.
Note: For the heat maps to work correctly, the access point placement on
the floor plan must closely match the actual physical location of the
access points.
The heat map shows the following information
• Signal strength and wireless coverage, including coverage holes.
• Known access points that are managed by the wireless controller
Chapter 3: RF Planning | 42
