ProSafe 20-AP Wireless Controller WC7520 Reference Manual
Table 7. Edit Access Point Settings (Continued)
Setting
Default Gateway
VLAN Settings
Untagged VLAN
Managed VLAN
Plan Settings
Building
Floor
Location
5. Click Apply.
Description
The default gateway of the access point. This field is populated during the access point
discovery process.
By default, the untagged VLAN is 1 and the Untagged VLAN check box is selected.
When the wireless controller sends frames associated with the untagged VLAN to the
LAN (Ethernet) interface, those frames are untagged. When the wireless controller
receives untagged traffic from the LAN (Ethernet) interface, those frames are assigned
to the untagged VLAN.
By default, the management VLAN is 1. For more information about management
VLANs, see VLANs on page 23 and
After you have configured buildings (see
page 38), select the building in which the access point is located from the drop-down
list.
After you have configured floors (see
page 38), select the floor on which the access point is located from the drop-down list.
Enter a name that is meaningful to you.
Chapter 4: Access Point Discovery and Management
Management VLANs on page 58.
Defining and Editing Buildings and Floors
Defining and Editing Buildings and Floors
on
on
| 53
