ProSafe 20-AP Wireless Controller WC7520 Reference Manual
Table 36. Network Summary Screen Information (Continued)
Setting
WPA2
Rogue Access Points
Rogue AP current
Rogue AP count 24hrs

Viewing Network Usage

Figure 84.
The Network Usage screen displays a graphic of the average data traffic rate that was
received and transmitted over the last 24 hours by all access points in the network. Select the
type of usage you want to display by clicking on one of the following tabs:
• 2.4 GHz Band Usage. Displays combined 802.11b-, 802.11bg-, and 802.11ng-mode
usage.
• 5 GHz Band Usage. Displays combined 802.11a- and 802.11na-mode usage.
• Network Usage. Displays Ethernet usage (shown in
Description
The number of wireless clients that are connected to managed access points using
security profiles configured with WPA2.
The total number of unique rogue and unmanaged neighboring access points that
are detected now in the network.
The total number of unique rogue and unmanaged neighboring access points that
were detected over the last 24 hours inn the network.
Chapter 11: Monitoring the Wireless Network and Components
Figure 84).
