4.2

Using Touch Panel Screens: Regular User

4.2.1 Common Buttons and Indicators

After the user logs in, the following buttons and indicators are shown on the touch panel screens.
Icon
ATTENTION

4.2 Using Touch Panel Screens: Regular User

Shown in manual as...
[Up] button, [Down] button
[OK] button
[Cancel] button
[Caps Lock] indicator
[Num Lock] indicator
If the [Logout] button or [Cancel] button is pressed before the [OK] button,
the contents of the screen will not be set.
Used to ...
Scroll up or down between items.
Set the contents of the current screen.
Cancel the contents of the current screen,
or return to the previous screen.
Indicate that the [Caps Lock] key has
been set (on the keyboard).
Indicate that the [Num Lock] key has
been set (on the keyboard).
