Novell ACCESS MANAGER 3.1 SP1 - GATEWAY GUIDE Manual page 158

Configuring the Remove the Path on Fill Option
If the path that is part of the published DNS name (/sales or /apps) is used to identify a resource but
is not part of directory configuration on the Web server, the path needs to be removed from the URL
before the request is sent to the Web server. For example, suppose you use the following
configuration:
Browser URL Using the Published DNS Name
http://www.test.com/sales
In this case, the path needs to be removed from the URL that the Access Gateway sends to the Web
server. The Access Gateway does not allow you to set up multiple paths to this type of Web server,
so all pages must have the same authentication requirements.
If the path in the published DNS name is a path on the Web server, the path needs to be passed to the
Web server as part of the URL. For example, suppose you use the following configuration:
Browser URL Using the Published DNS Name
http://www.test.com/sales
Because the path component specifies a directory on the Web server where the content begins, you
need to select to include the path. The Access Gateway then includes the path as part of the URL it
sends to the Web server. This configuration allows you to set up multiple paths to the Web server,
such as
sales/payroll
sales/reports
sales/products
Such a configuration also allows you to set up different authentication and authorization
requirements for each path.
Configuring the Host Header Option
When you create path-based proxy services and also enable the Remove Path on Fill option, you
need to know what types of links exist on the Web servers. For example, you need to know if the
sales Web servers in
servers. If they don't, you can set the Host Header option to either Forward Received Host Name or
to Web Server Host Name. However, if they do contain links to each other, you need to set the Host
Header option to Web Server Host Name and specify a DNS name for the Web server in the Web
Server Host Name option. The Access Gateway needs a method to distinguish between the Web
servers other than the path, because after the path is removed, all the Web servers in
page 157 have the same name: www.test.com.
If you select to use the Forward Received Host Name option for a path-based service, you might also
need to add entries to the Additional DNS Name List for the rewriter. For more information, see
"Determining Whether You Need to Specify Additional DNS Names" on page
158 Novell Access Manager 3.1 SP1 Access Gateway Guide
Figure 6-4 on page 157 have links to the app Web servers or to the test Web
Web Server URL
http://sales4.internal.com/
Web Server URL
http://sales4.internal.com/sales
Figure 6-4 on
44.
