Monitoring Access Gateway Alerts; Reviewing Java Alerts - Novell ACCESS MANAGER 3.1 SP1 - GATEWAY GUIDE Manual

2 To determine performance, analyze the following statistics:
Column
Server Name
CPU %
Cache Hit Rate %
Bytes per second to/from
Server
Bytes per second to/from
Browser
Current Connections
Statistics
3 Click Close.

4.4 Monitoring Access Gateway Alerts

The Access Gateway has been programmed to issue events to various types of systems (such as a
®
Novell Audit server or a Syslog server) so that the administrator can be informed when significant
changes occur that modify how the Access Gateway is performing. For information about auditing
and audit events, see
section describes how to use the following types of alerts:
Section 4.4.1, "Reviewing Java Alerts," on page 128
Section 4.4.2, "Configuring Access Gateway Alerts," on page 129

4.4.1 Reviewing Java Alerts

The Alerts page allows you to view information about current Java alerts and to clear them. An alert
is generated whenever the Access Gateway detects a condition that prevents it from performing
normal system services.
1 In the Administration Console, click Devices > Access Gateways > [Name of Server] > Alerts.
128 Novell Access Manager 3.1 SP1 Access Gateway Guide
Description
Lists the name of the Access Gateways that belong to the group. To
view additional statistical information about a specific Access
Gateway, click the name of an Access Gateway.
Displays the current CPU utilization rate. Use this statistic for capacity
planning.
Displays the current cache hit rate. A high cache hit rate indicates that
the caching system is off-loading significant request processing from
the Web server whose objects have been cached. If the percentage is
low, you might want to configure a pin list. For this and other caching
options, see Chapter 5, "Configuring the Content Settings," on
page 141.
Displays the rate at which the Access Gateway is requesting Web
objects from the Web servers it is protecting.
Displays the rate at which browser clients are requesting Web objects.
Displays the total number of TCP connections that are active, idle, or
closing.
Allows you to view all the statistics for a selected server. Click View to
see these additional statistics. For more information, see
"Monitoring Access Gateway Statistics," on page
Section 4.5, "Enabling Access Gateway Audit Events," on page
Section 4.3,
118.
133. This
