these protected resources could be assigned to this path-based service in the
Administration Console or used when access is requested.
4h Make sure the protected resource you created is enabled. If the resource is disabled, it does
not appear in the Path List for the path-based proxy service.
4i (Optional) Enable the policies the path-based proxy service requires. Click Authorization,
Identity Injection, or Form Fill and enable the appropriate policies.
4j Click OK.
5 To save your changes to browser cache, click OK.
6 To apply the changes, click the Access Gateways link, then click Update > OK.

6.3 Managing Multiple Reverse Proxies

Each reverse proxy must have a unique IP address and port combination. If your Access Gateway
has only one IP address, you must select unique port numbers for each additional reverse proxy that
you create. You can configure the Access Gateway to use multiple IP addresses. These addresses can
be configured to use the same network interface card, or if you have installed multiple network
cards, you can assign the IP addresses to different cards. To configure IP addresses and network
interface cards, see
If you are creating more than one reverse proxy, you must select one to be used for authentication.
By default, the first reverse proxy you create is assigned this task. Depending upon your Access
Gateway configuration, you might want to set up one reverse proxy specifically for handling
authentication. The authentication reverse proxy is also used for logout. If you have Web
applications that contain logout options, these options need to be redirected to the Logout URL of
the authentication proxy.
Section 6.3.1, "Managing Entries in the Reverse Proxy List," on page 164
Section 6.3.2, "Changing the Authentication Proxy Service," on page 165

6.3.1 Managing Entries in the Reverse Proxy List

1 In the Administration Console, click Devices > Access Gateways > Edit > Reverse Proxy /
Authentication.
164 Novell Access Manager 3.1 SP1 Access Gateway Guide
and ) and you have a path-based service with a path of
/apps /apps/*
Section 3.8.1, "Viewing and Modifying Adapter Settings," on page
, either of
/apps
90.
