Configuring a Domain-Based Multi-Homing Service for Novell Teaming
The following instructions describe how to set up a domain-based service to protect the Teaming
server. In this example, the published DNS name of the service is teaming.doc.provo.novell.com.
Users would access the Teaming server with a URL similar to the following: http://
teaming.doc.provo.novell.com/teaming. The /teaming is the default access path for the Teaming
application.
To configure a domain-based service for Teaming, complete the following tasks:
"Configuring the Domain-Based Proxy Service" on page 38
"Configuring Protected Resources" on page 38
"Configuring a Rewriter Profile" on page 39
Configuring the Domain-Based Proxy Service
1 In the Administration Console, click Devices > Access Gateways > Edit > [Name of Reverse
Proxy].
2 In the Reverse Proxy List, click New, then fill in the following fields:
Proxy Service Name: Specify a display name for the proxy service, which the Administration
Console uses for its interfaces.
Multi-Homing Type: Select Domain-Based.
Published DNS Name: Specify the DNS name you want the public to use to access your site.
This DNS name must resolve to the IP address you set up as the listening address. For example,
teaming.doc.provo.novell.com.
Web Server IP Address: Specify the IP address of the Novell Teaming server.
Host Header: Select the Web Server Host Name option.
Web Server Host Name: Specify the DNS name of the Teaming server.
3 Click OK.
4 Click the newly added proxy service, then select the Web Servers tab.
5 Change the Connect Port to 8080.
If the Teaming server has port forwarding enabled, you do not need to change from the default
port 80.
6 Click TCP Connect Options.
7 Change the value of Data Read Timeout option to 1200 seconds.
This longer timeout is needed for file uploads.
8 Click OK.
9 Continue with
Configuring Protected Resources
You need to create two protected resources, one for HTML content and one for WebDAV and AJAX
content.
1 Click Access Gateways > Edit > [Name of Reverse Proxy] > [Name of Proxy Service] >
Protected Resources.
