Intel
945G Express Chipset Development Kit User's Manual
Hardware References
4.4.3

IDE Connector

Table 26

IDE Connector

4.4.4

SATA Pinout

Table 27

SATA Pinout

Pin
1
2
3
4
5
6
7
50
Signal
GND
TXP
TXN
GND
RXN
RXP
GND
Reference #308823
