i1860 Scanner
Installation Planning Guide
A-61578

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i1860 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kodak i1860

  • Page 1 Scanner Installation Planning Guide A-61578...
  • Page 2: Table Of Contents

    Scanner clearance ........
  • Page 3: Safety Information

    A-61578 September 2006 CAUTION: Moving parts, avoid contact. CAUTION: Hot surface, avoid contact. The Kodak i1860 Scanner conforms to all applicable national and international product safety and electronic emission regulatory requirements. This includes, but is not limited to, the following:...
  • Page 4: Emc Statements

    此为A级产品,在生活环境中品可能会造成无线电干扰。在这种情况下,可能需要 用户对其干扰采取切实可行的措施 Compliance with regulations governing radio frequency emissions requires that the installation of your Kodak i1860 Scanner use the shielded data cable provided. Any data cable the user may choose to substitute also must be shielded to assure continued compliance.
  • Page 5: Korean

    Korean European Union Acoustic emission Power system connection A-61578 September 2006 Please note that this equipment has obtained EMC registration for commercial use. In the event that it has been mistakenly sold or purchased, please exchange it for equipment certified for home use. WARNING: THIS IS A CLASS A PRODUCT.
  • Page 6: Preparing The Site

    Preparing the Site Before delivery The Kodak i1860 Scanner is a new high speed, dual stream scanning platform which provides advanced image processing and superior throughput. The i1860 Scanner is designed to handle mixed document batches for any production scanning workflow.
  • Page 7: Delivery Day

    • The scanner will be moved to its final location. • The Computer Administrator will install the FireWire card and drivers. • The Kodak Field Engineer will train up to three operators on the operation of the scanner. Kodak will not train on the host scanner application.
  • Page 8: Dimensions And Weight

    Length: 99 cm (39 in.) Weight: 217.7 kg (480 lbs.) Place the i1860 Scanner in a location where there is sufficient space to allow for proper air flow and access for maintenance and repairs. Minimum clearances around the scanner Rear Right side 10.16 cm (4 in.)
  • Page 9: Requirements

    Temperature range: 15 to 35°C (59 to 95°F) Relative humidity: 15 to 76% (dry bulb) Static electricity — buildup of static electricity near the i1860 Scanner may cause operating problems. If the area is carpeted, it is recommended that the carpet is treated with an anti-static material or a conductive static mat is used.
  • Page 10: Ac Power Quality And Conditioning

    NOTE: All data was measured in accordance with DIN 45635, ANSI S12.10-1985, and ISO 7779 in a hemi-anechoic chamber. The i1860 Scanner can be on the same line as the host PC. The power cord must be used with a properly grounded outlet (15 amp duplex outlet).
  • Page 11 NOTE: The actual performance of the system depends on the scanning application, choice of scanning parameters, and the host computer configuration. If the scanner is not performing at the optimal speed, a faster computer and/or more RAM may be necessary to obtain the rated throughput.
  • Page 12: Installation Procedures

    Kodak Driver Software before you connect the scanner to the host computer. If you want, Kodak Service will install the 1394a (FireWire card) in the host computer. Kodak takes no responsibility for problems that may be caused by the installation of this hardware. If the host computer has a built-in 1394a (FireWire) port, the i1860 Scanner can be connected using this interface but it is not recommended.
  • Page 13: Installing The Firewire Cable

    CAUTION: DO NOT FORCE THE CONNECTOR. If the cable is not properly connected, it could cause damage to the scanner. The Kodak i1860 Scanner is packed with a set of power cords. 1. Select the power cord which complies with your electrical requirements and attach it.
  • Page 14: Supplies And Consumables

    Supplies and Consumables The following supplies are available. Order them in the United States by calling DI Supply at 1-888-247-1234 or contact your local Kodak Reseller. Outside of the United States, contact your local Kodak dealer. Supplies/Consumables Kodak Feeder Consumables Kit for i600/i1800 Series...
  • Page 15: Delivery And Installation Setup

    NOTE: All site preparation should be completed in advance of the equipment delivery. Kodak must be notified in advance of any special site requirements. These requirements include special delivery procedures, time restrictions and security clearance. The customer is responsible for inspecting the shipment and signing the Bill of Lading.
  • Page 16: Claims Process

    There is no minimum value for making a claim. An Equipment Delivery/Removal Survey is not required by Kodak Distribution for the i1860 Scanner. If your site has unique or difficult installation considerations, your Kodak representative must complete the Equipment Delivery/Removal Survey.
  • Page 17: Training

    • Key Operator Training Guide, A-61579 — after installation of your Kodak i1860 Scanner, the Field Engineer will use this guide to train operators on scanner usage and maintenance. • White Background Accessory Instructions, A-61576 — when you purchase the White Background Accessory, these instructions are included and provide a description of how to install the accessory.
  • Page 18: Standard Maintenance Service Terms And Conditions

    Product must also be covered by warranty or the same level Agreement. The term of the Agreement between Customer and Kodak shall be for one year, unless otherwise specified in writing. The terms and conditions set forth below plus the description of services and charges contained in the Kodak invoice and the provisions of the Agreement shall govern the relationship between the parties.
  • Page 19 2.1 Customer Software. Prior to service commencing on computers with hard drives, Customer is responsible for creating a back-up copy of the file from the hard drive. Kodak is only responsible for formatting (if required) and transferring those files deemed necessary for formatting as more precisely outlined in the formatting procedures for specific Products.
  • Page 20 5 business days after receiving the AUR. Kodak will pay the return transportation charges. If Customer does not...
  • Page 21 All software and/or changes are subject to the terms and conditions of the Kodak Software License Agreement that was in effect at the time the software is licensed from Kodak. License Terms are applicable as long as the software is being used, even if maintenance services are no longer available.
  • Page 22 NOTE: If Kodak determines that Parts needed to maintain or repair equipment are not available, Kodak will cancel the Agreement and issue a prorated credit for any remaining prepaid coverage. 5. Property of Kodak. Maintenance material, tools, documentation, diagnostics and test equipment provided by Kodak shall remain the exclusive property of Kodak.
  • Page 23 Kodak uses to protect its own information of a like nature. 9. Cancellation. Except as provided in Section 2.2 and section 4.J above, this Agreement may be canceled by either Customer or Kodak upon 30 days prior written notice.
  • Page 24 Payment terms are net 30 days from date of invoice, except for renewals, which are due by the renewal date. If payment has not been received by the due date, Kodak may, at its sole discretion, • cancel the invoice for non-payment. If the invoice is cancelled for...
  • Page 25 Eastman Kodak Company 343 State Street Rochester, NY 14650 USA © Kodak, 2006. TM: Kodak. PN 000000 www.kodak.com/go/docimaging...
